LOAD CELL 60060 340KG

Get a Price/Quote

MOQ : 1 Unit

LOAD CELL 60060 340KG Specification

Resistance
Input: 110030 , Output: 10005

Output
Analog Sensor

Theory
Resistance Strain Gauge

Type
Single Point Load Cell

Accuracy
0.02% of Rated Output

Operating Voltage
512 V DC (Recommended 10 V DC)

Output Voltage
2.0 mV/V 0.2 mV/V

Compensated Temperature
0C to +40C

Storage Temperature
-20C to +60C

Operating Temperature
-10C to +40C

LOAD CELL 60060 340KG Trade Information

Minimum Order Quantity
1 Unit

Main Domestic Market
All India

About LOAD CELL 60060 340KG

LOAD CELL 60060 340KG designed and developed by our company is commonly used in heavy-duty bottling plants to measure the weight of liquid-filled containers. It is ideal for direct mounting of large platforms with a single point of contact. The study aluminum body and unique shear beam design of this load-measuring transducer impart high strength and rigidity to bear extreme loads and vibrations. It is provided with a flexible cable to easily install it within the bottling plants. The offered LOAD CELL 60060 340KG can also be used within belt conveyor scales, hopper scales, counting scales, and check-weighing machines.

Premium Aluminum Alloy Construction

The LOAD CELL 60060 340KG is built from high-grade aluminum alloy, ensuring a robust yet lightweight sensor with excellent corrosion resistance. This construction allows for precise and long-lasting performance in various industrial environments, ensuring reliability for all your weighing applications.

Exceptional Accuracy and Protection

Delivering an accuracy of 0.02% of rated output and certified with an IP66 protection class, this load cell excels in both precision and durability. It resists dust and water ingress, providing dependable operation even in demanding conditions, making it ideal for consistent industrial use.

Versatile Industrial Applications

Engineered for compatibility with platform scales and a variety of weighing systems, the LOAD CELL 60060 340KG can be seamlessly integrated via top and bottom mounting threaded holes. Its analog output and 2-meter cable simplify installation, supporting accurate measurement processes across industries.

FAQs of LOAD CELL 60060 340KG:

Q: How is the LOAD CELL 60060 340KG installed for best performance?

A: This load cell is mounted using the threaded holes on its top and bottom surfaces, as indicated in the product datasheet. Proper alignment and secure mounting are essential to maximize accuracy and operational reliability in your weighing system.

Q: What environments can the LOAD CELL 60060 340KG operate in?

A: With an IP66 protection rating, the load cell is suitable for dusty and moist conditions. It operates efficiently in temperatures between -10C and +40C, making it ideal for most industrial environments within these temperature limits.

Q: When should I use this load cells safe and ultimate overload features?

A: Safe overload allows the sensor to withstand up to 150% of its rated capacity without damage, while the ultimate overload tolerance is up to 200%. These features provide a safety margin for unexpected weight loads, but regular use should not exceed the 340 kg rated capacity.

Q: Where can the LOAD CELL 60060 340KG be used?

A: This sensor is suitable for platform scales, industrial weighing systems, and applications requiring high precision and reliable analog output. It can be integrated into both new and existing weighing platforms in industrial, commercial, or research settings.

Q: What is the process of connecting and powering this load cell?

A: The load cell has a 2-meter cable for connection to your weighing indicator or data acquisition system. It operates on 512 V DC (recommended 10 V DC), and delivers an analog output of 2.0 mV/V 0.2 mV/V, ensuring clear signal transmission for accurate measurements.

Q: How does using this load cell benefit my weighing system?

A: Its high accuracy, robust construction, and reliable analog output ensure precise and stable measurements. The load cells overload protection and IP66 rating further extend operational safety and service life, contributing to the overall reliability and efficiency of your weighing application.
